Calculate low-lift vs high-lift compliance, mandatory base cleanout openings, allowable lift schedules, absorption wait times, and transit-mix grout yardage.
CMU estimates use nominal face dimensions and illustrative mortar yields (30 standard 8-inch units per 80-lb premix bag before waste; thickness adjustments apply). Confirm product yields, unit core volumes, supplier pack sizes and local prices before ordering. Reinforcement quantities are material allowances; laps, hooks, embedment and engineered design are excluded.
Compare code compliance thresholds, inspection milestones, and structural requirements under TMS 602 §3.5.
| Specification Parameter | Low-Lift Grouting | High-Lift Grouting | TMS 602 Reference |
|---|---|---|---|
| Maximum Pour Height | ≤ 5 ft 4 in (64 inches) | Up to 24 ft story height | TMS 602 §3.5.B |
| Cleanout Openings | Not mandatory by code | Mandatory at bottom of every grouted core | TMS 602 §3.5.B.2 |
| Cleanout Size Minimum | Optional visual window | 3" × 3" (or ≥ 12 sq in opening) | TMS 602 §3.5.B.2.a |
| Maximum Lift Height | Single lift up to 5 ft 4 in | 5.0 ft maximum per lift | TMS 602 §3.5.D.1 |
| Absorption Wait Time | None (single pour) | 30 to 60 minutes between lifts | TMS 602 §3.5.D.2 |
| Pencil Reconsolidation | Single consolidation pass | Mandatory reconsolidation 12"–24" into prior lift | TMS 602 §3.5.E |
| Typical Applications | Garden walls, short stem walls, 4-5 course rises | Basement stem walls, shear walls, commercial cores | IRC R404 / IBC 2104 |
High-lift grouting allows contractors to build masonry walls to full story height before pumping fluid ASTM C476 core fill. Successfully completing a high-lift pour requires strict adherence to site preparation, cleanout inspection, and vibration intervals:
Cut 3"×3" openings at the base course of all grouted cells. Remove face shell pieces neatly to create clean inspectable access ports.
Before closing cleanouts, flush all protruding mortar fins and construction debris from cells using high-pressure air or a water hose.
Cover cleanouts with temporary face-shell covers or form plywood braced with horizontal 2x4 walers to withstand fluid hydrostatic pressure.
Pump fluid ASTM C476 grout (8"–11" slump) in an initial lift not exceeding 5.0 feet. Mechanically consolidate with a pencil vibrator.
Pause 30 to 60 minutes between lifts. Porous CMU blocks absorb excess water, stiffening the grout and preventing lateral blowout.
Place the next 5-ft lift. Sink the pencil vibrator 12 to 24 inches into the prior lift to eliminate cold joints and air pockets.
Material estimates depend on the selected dimensions, product yields, and waste allowance.
